Overview:
• Measurement Type: Digital pressure sensing with four calibrated sensors
• Output Options: CAN 2.0B or RS485
• Applications: Pressure monitoring with simplified wiring and installation
• Explosion-Proof Rating: Exdb Ⅰ Mb, compliant with GB/T3836 standards
• Design: Stainless steel explosion-proof housing, space-efficient
Key Technical Specifications:
• Power Supply: 24V DC, (10–32)V DC
• Working Current: ≤ 300 mA
• Signal Output: CAN 2.0B or RS485, communication rate and high-level protocol details in user manual
• Display: OLED display
• Explosion-Proof Marking: Exdb Ⅰ Mb
• Temperature Compensation: -20°C to 70°C
• Protection Rating: IP54 (GB/T4208 compliant)
• Vibration Resistance: < 20 m/s²
• Explosion-Proof Design: Stainless steel housing, explosion-proof, IP54 protection, compliant cable entry per GB/T3836.1
